Camera ; Image Sensor , 1/2.9" CMOS ; Max. Resolution , 2688 (H) × 1520 (V) ; ROM , 128 MB ; RAM , 128 MB ; Scanning System , Progressive ; Electronic Shutter Speed , Auto/Manual 1/3 s–1/100,000 s ; Min. Illumination , 0.008 lux@F1.6 (Color, 30 IRE) 0.0008 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) ; S/N Ratio , >56 dB ; Illumination Distance , 30 m (98.43 ft) (IR), 30 m (98.43 ft) (Warm light) ; Illuminator On/Off Control , Auto; Manual ; Illuminator Number , 1 (IR LED); 1 (Warm light) ; Pan/Tilt/Rotation Range , Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° ; Lens ; Lens Type , Fixed-focal ; Lens Mount , M12 ; Focal Length , 2.8 mm; 3.6 mm ; Max. Aperture , F1.6 ; Field of View , 2.8 mm: H: 95°; V: 52°; D: 114° 3.6 mm: H: 78°; V: 41°; D: 94° ; Iris Control , Fixed ; Close Focus Distance , 2.8 mm: 0.9 m (2.95 ft); 3.6 mm: 1.6 m (5.25 ft) ; DORI Distance , Lens , Detect , Observe , Recognize , Identify ; 2.8 mm , 63.6 m (208.66 ft) , 25.4 m (83.33 ft) , 12.7 m (41.67 ft) , 6.4 m (20.99 ft) ; 3.6 mm , 85.4 m (280.18 ft) , 34.2 m (112.20 ft) , 17.1 m (56.10 ft) , 8.5 m (27.89 ft) ; Intelligence ; IVS (Perimeter Protection) , Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) ; Smart Search , Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos ; Video ; Video Compression , H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream) ; Smart Codec , Smart H.265+; Smart H.264+ ; Video Frame Rate , Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. ; Stream Capability , 2 streams ; Resolution , 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) ; Bit Rate Control , CBR/VBR ; Video Bit Rate , H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps ; Day/Night , Auto(ICR)/Color/B/W ; BLC , Yes ; HLC , Yes ; WDR , 120 dB ; White Balance , Auto; natural; street lamp; outdoor; manual; regional custom ; Gain Control , Auto;Manual ; Noise Reduction , 3D NR ; Motion Detection , OFF/ON (4 areas, rectangular) ; Region of Interest (RoI) , Yes (4 areas) ; Image Rotation , 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) ; Mirror , Yes ; Privacy Masking , 4 areas ; Audio ; Built-in MIC , Yes ; Audio Compression , G.711a; G.711Mu; PCM; G.726 ; Alarm ; Alarm Event , No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; SMD; voltage detection; security exception ; Network ; Network Port , RJ-45 (10/100 Base-T) ; SDK and API , Yes ; Network Protocol , IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP ; Interoperability , ONVIF (Profile S/Profile T); CGI; P2P; Milestone ; User/Host , 6 (Total bandwidth: 36 M) ; Storage , FTP; SFTP; Micro SD card (support max. 256 GB) ; Browser , IE; Chrome; Firefox ; Management Software , DSS; DMSS ; Mobile Client , iOS; Android ; Cyber Security , Configuration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout;syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification ; Certification ; Certifications , CE-LVD: EN 62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B ; Power ; Power Supply , 12 VDC/PoE (802.3af) ; Power Consumption , Basic: 2.1 W (12 VDC); 2.5 W (PoE) Max. (H.265 + intelligence + WDR + warm light): 4.4 W (12 VDC); 5.2 W (PoE) ; Environment ; Operating Temperature , –40 °C to +60 °C (–40 °F to +140 °F) ; Operating Humidity , ≤95% ; Storage Temperature , –40 °C to +60 °C (–40 °F to +140 °F) ; Protection , IP67 ; Structure ; Casing Material , Inner core: Metal ; Cover: Plastic ; Product Dimensions , 100.9 mm × Φ109.9 mm (3.97" × Φ4.33") ; Net Weight , 0.37 kg (0.82 lb) ; Gross Weight , 0.51 kg (1.12 lb) |
|---|
